FXJ-AT5050 Automatic Folding Lid Carton Sealer

PDF手册下载 CAD尺寸下载

•

  FXJ-AT5050自动折盖封箱机采用左右驱动的形式，气动式折盖机构，梯形丝杠的宽窄高低调节机构，高强度的结构设计，使得该机型性能可靠，能适应生产线连续的繁重的封箱工作。手动调节纸箱大小，适合同种规格纸箱同时段封箱；该折盖机操作简单、使用方便、容易调整、封箱速度快、效率高、坚固耐用，可单机使用，也可与自动化后道包装流水线、自动开箱机配套使用。适用于家用电器、纺织、食品、日用百货、药品、轻工、化工等各种行业产品包装、纸箱的封箱。



  FXJ-AT5050 automatic folding lid carton sealer adopts the left and right drive form, pneumatic cover folding mechanism ,trapezoidal screw width height adjusting mechanism, high structural strength design, making this machine reliable ,can adapt to continuous production line of heavy sealing cartons work. Manually adjust the carton size, suitable for the same carton sealing section ; The folding machine operation is simple, easy to use, easy to adjust, sealing speed, high efficiency, strong and durable, it can use single, also can with automatic packaging lines, automatic out of the machine after use. Applies to household appliances, textile, food, daily provisions, medicine, light industry, chemical industry and so on various products packaging, carton sealing.

•

  Mechanical arm, automatic folding cover.
  The feeder high speed unpacking machine and other automated production lines,easy to use.
•



  Model	FXJ-AT5050
  Voltage	220V 50HZ
  Power	200W
  Max.packager size	L600*W500*H500MM
  Min.packager size	L200*W150*H130MM
  Conveyor speed	300-750boxes/h
  Tape width	2"、2.5"、3"
  Packing size	L1700*W900*H1500MM
  Machine weight	180KG

•
